Komatsu JV40DW-3
Contents:
| Overall Length | 10.18 in (3100 mm) |
| Overall Width | 4.57 ft in (1390 mm) |
| Height To Top Of Cab | 5.75 ft in (1750 mm) |
| Wheelbase | 7.55 in (2300 mm) |
| Ground Clearance | 9.85 in (250 mm) |
| Drum Diameter - Front | 2.63 ft in (800 mm) |
| Number Of Cylinders | 3 |
| Engine Make | 2238 |
| Engine Model | 3D84E |
| Gross Power | 27.7 hp (20.6 kw) |
| Power Measured @ | 2700 rpm |
| Displacement | 87.3 cu in (1.5 L) |
| Operating Weight | 8598.1 lb (3900 kg) |
| Fuel Capacity | 12.5 gal (47 L) |
| Max Speed | 6.6 mph (10.5 km/h) |
| Drum Width | 51.2 in (1300 mm) |
| Drum Diameter | 31.5 in (800 mm) |
| Vibration Frequency 1 | 55 Hz |
| Centrifugal Force - Med | 5510 lb (- kN) |
