Ingersoll Rand SD160DXTF
Browse All Ingersoll Rand or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 19.67 in (5994 mm) |
| Overall Width | 8.16 ft in (2486 mm) |
| Height To Top Of Cab | 10.22 ft in (3114 mm) |
| Wheelbase | 10.17 in (3099 mm) |
| Ground Clearance | 20.99 in (533 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | B5.9-TAA |
| Gross Power | 173 hp (129.1 kw) |
Operational
| Operating Weight | 35194.6 lb (15964 kg) |
| Fuel Capacity | 67.9 gal (257 L) |
| Hydraulic System Fluid Capacity | 27.5 gal (104 L) |
| Max Speed | 7.8 mph (12.4 km/h) |
| Tires *If Applicable | 23.1x26-8PR R3 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
Drum
| Drum Width | 84.1 in (2134 mm) |
| Drum Diameter | 63 in (1600 mm) |
| Vibration Frequency 1 | 20.4 Hz |
| Nominal Amplitude - High | 0.1 in (2 mm) |
| Vibration Frequency 2 | 33.8 Hz |
| Nominal Amplitude - Low | 0.1 in (1.3 mm) |
| Centrifugal Force - High | 76210.3 lb (339 kN) |
| Centrifugal Force - Low | 59349.6 lb (264 kN) |
