Dynapac CC722
Browse All Dynapac or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 18.55 in (5653 mm) |
| Overall Width | 7.73 ft in (2354 mm) |
| Height To Top Of Cab | 11.26 ft in (3430 mm) |
| Wheelbase | 12.32 in (3754 mm) |
| Ground Clearance | 15.75 in (400 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | QSB 6.7 T3 |
| Gross Power | 228 hp (170 kw) |
| Power Measured @ | 2100 rpm |
| Aspiration | water cooled turbo diesel with after cooler |
Operational
| Operating Weight | 36982.6 lb (16775 kg) |
| Fuel Capacity | 88.5 gal (335 L) |
| Max Speed | 6.9 mph (11 km/h) |
Drum
| Drum Width | 83.9 in (2130 mm) |
| Drum Diameter | 60.2 in (1527 mm) |
| Static Linear Load | lb/in (40 kg/cm) |
| Vibration Frequency 1 | 48 Hz |
| Nominal Amplitude - High | 0.1 in (0.7 mm) |
| Nominal Amplitude - Low | 0.1 in (0.4 mm) |
| Centrifugal Force - High | 48334 lb (215 kN) |
| Centrifugal Force - Low | 22930.6 lb (102 kN) |
