Dynapac CC624HFCE
Browse All Dynapac or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 16.38 in (4990 mm) |
| Overall Width | 7.61 ft in (2319 mm) |
| Height To Top Of Cab | 9.81 ft in (2990 mm) |
| Wheelbase | 12.11 in (3690 mm) |
| Ground Clearance | 12.21 in (310 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | QSB 4.5 T3 |
| Gross Power | 125 hp (93 kw) |
| Power Measured @ | 2200 rpm |
| Aspiration | water cooled turbo diesel with after cooler |
Operational
| Operating Weight | 27778.3 lb (12600 kg) |
| Fuel Capacity | 63.5 gal (240 L) |
| Max Speed | 7.5 mph (12 km/h) |
Drum
| Drum Width | 83.9 in (2130 mm) |
| Drum Diameter | 51.2 in (1300 mm) |
| Static Linear Load | lb/in (30 kg/cm) |
| Vibration Frequency 1 | 43 Hz |
| Nominal Amplitude - High | 0.1 in (0.8 mm) |
| Vibration Frequency 2 | 62 Hz |
| Nominal Amplitude - Low | 0.1 in (0.2 mm) |
| Centrifugal Force - High | 26077.9 lb (116 kN) |
| Centrifugal Force - Low | 13713.4 lb (61 kN) |
