Dynapac CC3300
Browse All Dynapac or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 177 in (4495.8 mm) |
| Overall Width | 6.09 ft in (1854.2 mm) |
| Height To Top Of Cab | 9.84 ft in (2997.2 mm) |
| Wheelbase | 131 in (3327.4 mm) |
| Ground Clearance | 11 in (279.4 mm) |
| Gradeability | 35 % |
| Turning Radius - Inside | 16.25 ft in (4953 mm) |
| Turning Radius - Outside | 21.92 ft in (6680.2 mm) |
| Curb Clearance | 28 in (711.2 mm) |
Engine
| Engine Make | Deutz |
| Engine Model | TCD 3.6 HT |
| Engine Type | Water cooled turbo diesel |
| Gross Power | 74 hp (55.2 kw) |
| Power Measured @ | 2200 rpm |
Operational
| Operating Weight Rops | 43651.6 lb (19800 kg) |
| Oscillating Angle | 7 degrees |
| Operating Weight | 48060.8 lb (21800 kg) |
| Fuel Capacity | 34 gal (128.8 L) |
| Water Spray Tank Fluid Capacity | 198 gal (749.6 L) |
| Max Speed | 4.7 mph (7.5 km/h) |
| Steering Angle | 32 degrees |
Drum
| Drum Thickness | 0.7 in (17.8 mm) |
| Drum Width | 68 in (1727.2 mm) |
| Drum Diameter | 45 in (1143 mm) |
| Static Linear Load | 146 lb/in (26.1 kg/cm) |
| Vibration Frequency 1 | 48 Hz |
| Nominal Amplitude - High | 0.2 in (5.1 mm) |
| Vibration Frequency 2 | 67 Hz |
| Nominal Amplitude - Low | 0.1 in (2.6 mm) |
| Centrifugal Force - High | 18440 lb (82.1 kN) |
| Centrifugal Force - Low | 16190 lb (72.1 kN) |
