Dynapac CA1300PD
Browse All Dynapac or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 156 in (3962.4 mm) |
| Wheelbase | 73 in (1854.2 mm) |
| Ground Clearance | 10 in (254 mm) |
| Height With Out Rops | 71 ft in (21640.8 mm) |
| Height With Rops | 8.34 ft in (2540 mm) |
| Gradeability | 52 % |
| Overhang Front | 0.17 ft in (50.81 mm) |
| Overhang Rear | 0.17 ft in (50.81 mm) |
| Turning Radius - Inside | 8 ft in (2438.4 mm) |
| Turning Radius - Outside | 13 ft in (3962.4 mm) |
| Curb Clearance | 10 in (254 mm) |
Engine
| Engine Make | Kubota |
| Engine Model | V 3307 CR-TE4 |
| Engine Type | Water cooled turbo Diesel |
| Gross Power | 75 hp (56 kw) |
| Power Measured @ | 2200 rpm |
Operational
| Operating Weight Rops | 10500 lb (4762.8 kg) |
| Operating Weight | 11500 lb (5216.4 kg) |
| Fuel Capacity | 31 gal (117.4 L) |
| Max Speed | 4 mph (6.5 km/h) |
| Tire Size | 12.5-20 |
Drum
| Drum Thickness | 0.9 in (22.1 mm) |
| Drum Width | 54 in (1371.6 mm) |
| Drum Diameter | 39 in (990.6 mm) |
| Centrifugal Force - High | 20000 lb (89 kN) |
