JCB VM46PD
Browse All JCB or Vibratory Compactor Models
Contents:
Dimensions
| Overall Length W/O Blade | 14.36 ft in (4375 mm) |
| Width Over Tires | 4.99 ft in (1520 mm) |
| Height To Top Of Cab | 8.67 ft in (2640 mm) |
| Wheelbase | 7.22 in (2200 mm) |
| Ground Clearance | 13.19 in (335 mm) |
Drum
| Drum Diameter | 35.83 in (910 mm) |
| Number Of Pads | 77 |
| Drum Width | 55.12 in (1400 mm) |
| Nominal Amplitude - High | 0.06 in (1.5 mm) |
| Centrifugal Force - High | 22841 lb (101.61 kN) |
| Pad Height | 3.15 in (80 mm) |
| Vibration Frequency 1 | 32 Hz |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2347 |
| Engine Model | B 3.3 |
| Gross Power | 60 hp (44.8 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 199 cu in (3.3 L) |
Operational
| Operating Weight | 10802.7 lb (4900 kg) |
| Fuel Capacity | 47.6 gal (180 L) |
| Cooling System Fluid Capacity | 3.7 gal (14 L) |
| Engine Oil Capacity | 2.2 gal (8 L) |
| Hydraulic System Fluid Capacity | 15.9 gal (60 L) |
| Max Speed | 7.9 mph (12.7 km/h) |
| Tires | 12.4-24 Dyna Torque |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 60 amps |
