JCB VM200PD
Browse All JCB or Vibratory Compactor Models
Contents:
Dimensions
| Overall Length W/O Blade | 19.68 ft in (5996 mm) |
| Width Over Tires | 7.45 ft in (2270 mm) |
| Height To Top Of Cab | 9.8 ft in (2985 mm) |
| Wheelbase | 10.1 in (3076 mm) |
| Ground Clearance | 19.57 in (497 mm) |
Drum
| Drum Diameter | 63 in (1600 mm) |
| Vibratory Frequency 2 | 35 Hz |
| Number Of Pads | 132 |
| Drum Width | 82.68 in (2100 mm) |
| Nominal Amplitude - High | 0.03 in (0.75 mm) |
| Centrifugal Force - High | 83179 lb (370 kN) |
| Pad Height | 3.9 in (99.06 mm) |
| Vibration Frequency 1 | 29 Hz |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | B5.9 - 173C |
| Gross Power | 173 hp (129.1 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 359 cu in (5.9 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 43431.1 lb (19700 kg) |
| Fuel Capacity | 84.6 gal (320 L) |
| Cooling System Fluid Capacity | 5.1 gal (19 L) |
| Engine Oil Capacity | 3.9 gal (14.5 L) |
| Hydraulic System Fluid Capacity | 21.2 gal (80 L) |
| Max Speed | 7.4 mph (11.8 km/h) |
| Tires | 23.1-26/12 Tractor Tread |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
