Hamm H20i C P
Browse All Hamm or Vibratory Compactor Models
Contents:
Dimensions
| Height To Top Of Cab | 9.75 ft in (2970 mm) |
| Wheelbase | 128.55 in (3265 mm) |
| Ground Clearance | 15.36 in (390 mm) |
| Turning Radius - Inside | 13.78 ft in (4200 mm) |
| Overall Width | 7.58 ft in (2308 mm) |
| Overall Length | 21.66 ft in (6600 mm) |
Drum
| Drum Diameter | 70.24 in (1784 mm) |
| Pad Height | 3.94 in (100 mm) |
| Vibration Frequency 1 | 27 Hz |
| Vibratory Frequency 2 | 30 Hz |
| Nominal Amplitude - Low | 0.05 in (1.14 mm) |
| Centrifugal Force - Low | 54403.76 lb (242 kN) |
| Drum Thickness | 1.38 in (35 mm) |
| Drum Width | 84.26 in (2140 mm) |
| Nominal Amplitude - High | 0.08 in (1.93 mm) |
| Centrifugal Force - High | 74411.76 lb (331 kN) |
| Number Of Pads | 150 |
Engine
| Emissions Level | EU Stage IV / EPA Tier 4 |
| Number Of Cylinders | 6 |
| Engine Make | DEUTZ |
| Engine Model | TCD 6.1 L6 |
| Gross Power | 214.6 hp (160 kw) |
| Net Power | 214.6 hp (160 kw) |
| Power Measured @ | 2300 rpm |
Operational
| Smooth Drum Operating Weight With Cab | 45845.2 lb (20795 kg) |
| Def Tank Capacity | 8.5 gal (32 L) |
| Oscillating Angle | 10 degrees |
| Operating Weight | 46142.8 lb (20930 kg) |
| Fuel Capacity | 74 gal (280 L) |
| Max Speed | 6.3 mph (10 km/h) |
| Tires | TR 23.1-26 12 PR |
