Caterpillar CP653
Browse All Caterpillar or Vibratory Compactor Models
Contents:
Dimensions
| Overall Length W/O Blade | 20.18 ft in (6150 mm) |
| Width Over Tires | 8.08 ft in (2460 mm) |
| Height To Top Of Cab | 12.14 ft in (3700 mm) |
Drum
| Drum Diameter | 66.93 in (1700 mm) |
| Centrifugal Force - High | 48995 lb (217.95 kN) |
| Drum Width | 86.62 in (2200 mm) |
| Vibration Frequency 1 | 32.5 Hz |
Engine
| Engine Make | 2236 |
| Engine Model | 3304 |
| Gross Power | 134.2 hp (100 kw) |
| Displacement | 427.2 cu in (7 L) |
Operational
| Operating Weight | 40785.6 lb (18500 kg) |
| Fuel Capacity | 60.8 gal (230 L) |
| Engine Oil Capacity | 5.9 gal (22 L) |
| Hydraulic System Fluid Capacity | 34.4 gal (130 L) |
| Max Speed | 9.7 mph (15.5 km/h) |
| Tires | 20.5x25 XRA |
