Ammann ASC90PD
Contents:
| Overall Length W/O Blade | 17.05 ft in (5195 mm) |
| Width Over Tires | 6.34 ft in (1930 mm) |
| Height To Top Of Cab | 9.42 ft in (2870 mm) |
| Wheelbase | 8.4 in (2560 mm) |
| Ground Clearance | 15.16 in (385 mm) |
| Drum Diameter | 48.82 in (1240 mm) |
| Pad Height | 3.15 in (80 mm) |
| Pad Surface Area | 17.68 in2 (11400 cm2) |
| Vibration Frequency 1 | 30 Hz |
| Vibratory Frequency 2 | 40 Hz |
| Number Of Pads | 104 |
| Centrifugal Force - Low | 35969.43 lb (160 kN) |
| Drum Width | 66.15 in (1680 mm) |
| Nominal Amplitude - High | 0.04 in (0.96 mm) |
| Nominal Amplitude - Low | 0.08 in (1.85 mm) |
| Centrifugal Force - High | 32597.3 lb (145 kN) |
| Number Of Cylinders | 4 |
| Engine Make | 2347 |
| Engine Model | B4.5-C99 |
| Net Power | 101 hp (75.4 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 274.7 cu in (4.5 L) |
| Operating Weight | 19323.6 lb (8765 kg) |
| Fuel Capacity | 72.7 gal (275 L) |
| Max Speed | 6.9 mph (11 km/h) |
| Tires | 14.9-24 |
