JLG 544D10-55
Browse All JLG or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 19.72 ft in (6010 mm) |
| Ground Clearance | 1.74 ft in (528 mm) |
| Width Over Tires | 8.21 ft in (2500 mm) |
| Overall Height | 8.14 ft in (2480 mm) |
| Wheelbase | 11.23 ft in (3420 mm) |
| Turning Radius Outside Tires | 14.57 ft in (4440 mm) |
Lift
| Max Lift Height | 55.12 ft in (16800 mm) |
| Max Forward Reach | 42 ft in (12800 mm) |
| Max Load At Max Reach | _ - ( ) |
| Max Load At Max Height | 3999.19 lb (1814 kg) |
| Max Lift Capacity | 10000.17 lb (4536 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2347 |
| Engine Model | QSB4.5 |
| Gross Power | 130.1 hp (97 kw) |
| Power Measured @ | 2500 rpm |
| Displacement | 274.7 cu in (4.5 L) |
| Aspiration | turbocharged, aftercooled |
Operational
| Operating Weight | 33999.7 lb (15422 kg) |
| Fuel Capacity | 38.1 gal (144 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
| Drawbar Pull | 18399.8 lb (8346 kg) |
| Tire Size | 14.0x24-12PR |
Transmission
| Transmission Type | hydrostatic |
| Max Speed - Forward | 19.1 mph (30.6 km/h) |
Hydraulic
| Pump Type | single-section gear |
| Pump Flow Capacity | 40 gal/min (151.4 L/min) |
