Genie GTH5022R
Browse All Genie or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 24.78 ft in (7550 mm) |
| Ground Clearance | 1.42 ft in (430 mm) |
| Width Over Tires | 8.17 ft in (2490 mm) |
| Overall Height | 10.01 ft in (3050 mm) |
| Wheelbase | 11.49 ft in (3500 mm) |
| Turning Radius Outside Tires | 15.82 ft in (4820 mm) |
Lift
| Max Lift Height | 71.63 ft in (21830 mm) |
| Max Forward Reach | 62.11 ft in (18930 mm) |
| Max Load At Max Reach | 881.85 lb (400 kg) |
| Max Load At Max Height | 5511.56 lb (2500 kg) |
| Max Lift Capacity | 11023.12 lb (5000 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 1106D-E66TA, Tier III |
| Gross Power | 156.3 hp (116.5 kw) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 42439 lb (19250 kg) |
| Fuel Capacity | 33.1 gal (125 L) |
| Hydraulic System Fluid Capacity | 52.9 gal (200 L) |
| Tire Size | 445/65 R 22.5 |
Transmission
| Transmission Type | hydrostatic, two speed mechanical gearbox |
| Number Of Forward Gears | 2 |
| Max Speed - Forward | 18.7 mph (30 km/h) |
Hydraulic
| Pump Type | variable displacement |
| Pump Flow Capacity | 34.4 gal/min (130 L/min) |
| Relief Valve Pressure | 3926 psi (27068.8 kPa) |
