Genie GTH4013EX
Browse All Genie or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 19.89 ft in (6060 mm) |
| Ground Clearance | 1.28 ft in (390 mm) |
| Width Over Tires | 7.62 ft in (2320 mm) |
| Overall Height | 7.88 ft in (2400 mm) |
| Wheelbase | 9.68 ft in (2950 mm) |
| Turning Radius Outside Tires | 15.26 ft in (4650 mm) |
Lift
| Max Lift Height | 42.66 ft in (13000 mm) |
| Max Forward Reach | 29.79 ft in (9080 mm) |
| Max Load At Max Reach | 2755.78 lb (1250 kg) |
| Max Load At Max Height | 6613.87 lb (3000 kg) |
| Max Lift Capacity | 8818.49 lb (4000 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 1104 D-44T, Tier III |
| Gross Power | 99.3 hp (74 kw) |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 22266.7 lb (10100 kg) |
| Fuel Capacity | 35.7 gal (135 L) |
| Hydraulic System Fluid Capacity | 39.7 gal (150 L) |
| Tire Size | 405/70 20 PR14 |
Transmission
| Transmission Type | hydrostatic, two speed mechanical gearbox |
| Number Of Forward Gears | 2 |
| Max Speed - Forward | 21.8 mph (35 km/h) |
Hydraulic
| Pump Type | variable displacement |
| Pump Flow Capacity | 25.1 gal/min (95 L/min) |
| Relief Valve Pressure | 3916 psi (26999.9 kPa) |
