Gehl 6L
Browse All Gehl or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 20.02 ft in (6100 mm) |
| Width Over Tires | 7.88 ft in (2400 mm) |
| Overall Height | 7.88 ft in (2400 mm) |
| Wheelbase | 12.14 ft in (3700 mm) |
Lift
| Max Lift Height | 41.02 ft in (12500 mm) |
| Max Forward Reach | 26.91 ft in (8200 mm) |
| Max Load At Max Reach | 1499.15 lb (680 kg) |
| Max Load At Max Height | 6999.68 lb (3175 kg) |
| Max Lift Capacity | 6999.68 lb (3175 kg) |
Engine
| Engine Make | 2240 |
| Net Power | 115 hp (85.8 kw) |
| Aspiration | turbo diesel |
Operational
| Operating Weight | 23097.9 lb (10477 kg) |
| Fuel Capacity | 30 gal (113.5 L) |
| Hydraulic System Fluid Capacity | 45 gal (170.3 L) |
Transmission
| Transmission Type | 4-speed power-shift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
