Volvo MC110
Browse All Volvo or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 11.65 ft in (3550 mm) |
| Width Over Tires | 6 ft in (1826 mm) |
| Ground Clearance | 7.41 in (188 mm) |
| Height To Top Of Cab | 6.76 ft in (2058 mm) |
| Wheelbase | 3.65 ft in (1112 mm) |
| Length W/O Bucket | 9.26 ft in (2821 mm) |
| Clearance At Max Lift And Dump | 7.86 ft in (2394 mm) |
| Reach At Max Lift And Dump | 24.61 in (625 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 1004.42 |
| Gross Power | 86 hp (64.2 kw) |
| Power Measured @ | 2400 rpm |
| Displacement | 258 cu in (4.3 L) |
Operational
| Operational Weight | 7654 lb (3471.8 kg) |
| Fuel Capacity | 22.5 gal (85 L) |
| Cooling System Fluid Capacity | 4.1 gal (15.5 L) |
| Engine Oil Fluid Capacity | 2.8 gal (10.4 L) |
| Max Speed | 6 mph (9.6 km/h) |
| Hydraulic System Fluid Capacity | 17 gal (64 L) |
| Chain Box Fluid Capacity - Each Side | 2.3 gal (8.7 L) |
| Operating Speed | 6 mph (9.6 km/h) |
| Tire Size | 12.00x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 amps |
Loader
| Operating Load Rating | 2300 lb (1043.3 kg) |
| Tipping Angle | 4600 degrees |
| Bucket Capacity | 0.7 yd3 (0.5 m3) |
Hydraulic
| Pump Flow Capacity | 20.3 gal/min (76.9 L/min) |
| Relief Valve Pressure | 2700 psi (18615.9 kPa) |
