John Deere 60
Browse All John Deere or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 7.98 ft in (2432 mm) |
| Width Over Tires | 2.96 ft in (902 mm) |
| Ground Clearance | 5 in (127 mm) |
| Height To Top Of Cab | 6.21 ft in (1892 mm) |
| Wheelbase | 2.44 ft in (741 mm) |
| Clearance At Max Lift And Dump | 6.07 ft in (1848 mm) |
| Reach At Max Lift And Dump | 13.51 in (343 mm) |
| Turning Radius From Center - Machine Rear | 45.75 in (1162 mm) |
| Turning Radius From Center - Inc Bucket | 45.75 in (1162 mm) |
Engine
| Number Of Cylinders | 2 |
| Engine Make | 2355 |
| Engine Model | KT17 |
| Net Power | 17 hp (12.7 kw) |
| Power Measured @ | 3400 rpm |
| Displacement | 42.2 cu in (0.7 L) |
Operational
| Operational Weight | 2076 lb (942 kg) |
| Fuel Capacity | 5 gal (18.9 L) |
| Max Speed | 4.3 mph (6.9 km/h) |
| Hydraulic System Fluid Capacity | 18 gal (68 L) |
| Operating Speed | 4.3 mph (6.9 km/h) |
| Tire Size | 5.70-12 |
| Operating Voltage | 12 V |
Loader
| Operating Load Rating | 600 lb (272 kg) |
| Tipping Angle | 1200 degrees |
| Bucket Capacity | 0.2 yd3 (0.2 m3) |
Hydraulic
| Pump Type | Open-center |
| Pump Flow Capacity | 7.5 gal/min (28.4 L/min) |
| Relief Valve Pressure | 1500 psi (103.4 kPa) |
