JCB 280
Browse All JCB or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 12.34 ft in (3760 mm) |
| Width Over Tires | 6.01 ft in (1830 mm) |
| Ground Clearance | 9.38 in (238 mm) |
| Height To Top Of Cab | 6.86 ft in (2090 mm) |
| Wheelbase | 4.01 ft in (1220 mm) |
| Clearance At Max Lift And Dump | 8.08 ft in (2460 mm) |
| Reach At Max Lift And Dump | 34.26 in (870 mm) |
| Turning Radius From Center - Machine Rear | 69.3 in (1760 mm) |
| Turning Radius From Center - Inc Bucket | 86.62 in (2200 mm) |
Engine
| Engine Make | 2257 |
| Engine Model | TC-63 |
| Gross Power | 84 hp (62.7 kw) |
| Power Measured @ | 2400 rpm |
| Max Torque | 267 lb ft (362.1 Nm) |
| Torque Measured @ | 1800 rpm |
| Aspiration | Turbocharged |
| Displacement | 268 cu in (4.4 L) |
Operational
| Operational Weight | 8060 lb (3656 kg) |
| Fuel Capacity | 27.3 gal (103 L) |
| Cooling System Fluid Capacity | 4.1 gal (15.5 L) |
| Engine Oil Fluid Capacity | 3.7 gal (14 L) |
| Hydraulic System Fluid Capacity | 15.9 gal (60 L) |
| Max Speed | 12.4 mph (20 km/h) |
| Chain Box Fluid Capacity - Each Side | 6.1 gal (23 L) |
| Operating Speed | 6.8 mph (11 km/h) |
| Tire Size | 12 x 16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
Loader
| Operating Load Rating | 2800 lb (1270.1 kg) |
| Tipping Angle | 5608 degrees |
| Bucket Capacity | 0.7 yd3 (0.5 m3) |
Hydraulic
| Pump Flow Capacity | 23 gal/min (87.1 L/min) |
| Relief Valve Pressure | 3335 psi (22994 kPa) |
