Gehl V270
Browse All Gehl or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 12.44 ft in (3790 mm) |
| Width Over Tires | 5.8 ft in (1765 mm) |
| Ground Clearance | 8 in (203 mm) |
| Height To Top Of Cab | 6.71 ft in (2045 mm) |
| Wheelbase | 4.16 ft in (1265 mm) |
| Length W/O Bucket | 9.59 ft in (2921 mm) |
| Clearance At Max Lift And Dump | 8.26 ft in (2515 mm) |
| Reach At Max Lift And Dump | 34.02 in (864 mm) |
| Turning Radius From Center - Machine Rear | 65.52 in (1664 mm) |
| Turning Radius From Center - Inc Bucket | 93 in (2362 mm) |
Engine
| Engine Make | 2348 |
| Engine Model | 4TNV98T-ZNMS |
| Net Power | 84 hp (62.7 kw) |
| Power Measured @ | 2500 rpm |
| Max Torque | 215 lb ft (291.6 Nm) |
| Torque Measured @ | 1650 rpm |
| Displacement | 202 cu in (3.4 L) |
Operational
| Operational Weight | 8000 lb (3628.8 kg) |
| Fuel Capacity | 22 gal (83.3 L) |
| Max Speed | 11.9 mph (19.2 km/h) |
| Hydraulic System Fluid Capacity | 11 gal (41.7 L) |
| Operating Speed | 8.1 mph (13.1 km/h) |
Loader
| Operating Load Rating | 2700 lb (1224.7 kg) |
Hydraulic
| Pump Flow Capacity | 21.8 gal/min (82.4 L/min) |
| Relief Valve Pressure | 3350 psi (23097.5 kPa) |
