Case 430
Browse All Case or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 10.6 ft in (3230 mm) |
| Width Over Tires | 4.4 ft in (1340 mm) |
| Ground Clearance | 9 in (229 mm) |
| Height To Top Of Cab | 6.4 ft in (1950 mm) |
| Wheelbase | 3.61 ft in (1100 mm) |
| Length W/O Bucket | 8.67 ft in (2640 mm) |
| Clearance At Max Lift And Dump | 8.04 ft in (2450 mm) |
| Reach At Max Lift And Dump | 21.3 in (540 mm) |
| Turning Radius From Center - Machine Rear | 59.1 in (1500 mm) |
| Turning Radius From Center - Inc Bucket | 76.7 in (1950 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2239 |
| Engine Model | Family III 445/M2, Tier II certified |
| Gross Power | 80 hp (60 kw) |
| Net Power | 74 hp (55.2 kw) |
| Power Measured @ | 2300 rpm |
| Aspiration | naturally aspirated |
| Displacement | 274 cu in (4.5 L) |
Operational
| Operational Weight | 6875 lb (3119 kg) |
| Fuel Capacity | 22 gal (83.3 L) |
| Cooling System Fluid Capacity | 4.5 gal (17 L) |
| Engine Oil Fluid Capacity | 3.2 gal (12 L) |
| Max Speed | 11.9 mph (19.2 km/h) |
| Hydraulic System Fluid Capacity | 13.3 gal (50.2 L) |
| Chain Box Fluid Capacity - Each Side | 1.5 gal (5.7 L) |
| Tire Size | 12.00 x 16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
Loader
| Operating Load Rating | 2000 lb (908 kg) |
| Tipping Angle | 4000 degrees |
| Bucket Capacity | 0.6 yd3 (0.5 m3) |
Hydraulic
| Pump Type | Gear |
| Pump Flow Capacity | 21 gal/min (79.5 L/min) |
| Relief Valve Pressure | 3000 psi (20684.3 kPa) |
