Bobcat S450
Browse All Bobcat or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 10.42 ft in (3173 mm) |
| Width Over Tires | 4.89 ft in (1488 mm) |
| Ground Clearance | 8.39 in (213 mm) |
| Height To Top Of Cab | 6.49 ft in (1976 mm) |
| Wheelbase | 2.95 ft in (899 mm) |
| Length W/O Bucket | 8.2 ft in (2499 mm) |
| Clearance At Max Lift And Dump | 7.11 ft in (2166 mm) |
| Reach At Max Lift And Dump | 20.79 in (528 mm) |
Engine
| Emission Tier Level | Tier 4 |
| Gross Power | 49 hp (36.6 kw) |
| Cooling System | Liquid |
| Aspiration | Turbocharged |
| Fuel Type | Turbo Diesel |
Operational
| Lift Arm Path | Radius |
| Operational Weight | 5026.6 lb (2280 kg) |
| Fuel Capacity | 14.4 gal (54.6 L) |
| Max Speed | 7.1 mph (11.5 km/h) |
Loader
| Loader Series | M2-Series |
| Height To Hinge Pin | 9.2 ft in (2781 mm) |
| Operating Load Rating | 1300 lb (589.7 kg) |
| Tipping Angle | 2599.3 degrees |
| Bucket Width | 62.1 in (1575 mm) |
Hydraulic
| Main Pump Flow Standard | 16.7 gal/min (63.3 L/min) |
| Relief Valve Pressure | 3300 psi (22752.7 kPa) |
