Komatsu PC650-1
Contents:
Dimensions
| Width Over Tracks | _ - (3910 mm) |
| Length Of Track On Ground | 14.8 ft in (4510 mm) |
| Height To Top Of Cab | 14.54 ft in (4430 mm) |
| Ground Clearance | 2.04 in (620 mm) |
| Upper Structure Ground Clearance | 3.86 ft in (1175 mm) |
| Length Of Tracks | 18.92 ft in (5765 mm) |
Loading Shovel
| Max Dig Reach | 32.81 ft in (10000 mm) |
| Max Dump Height | 24.48 ft in (7460 mm) |
| Max Cutting Height | 34.78 ft in (10600 mm) |
| Max Dig Depth | 11.49 ft in (3500 mm) |
| Arm Crowd Force | 99210 lb ft (441 Nm) |
| Loading Shovel | Boom 15'5" (4690mm)/Stick 10'6" (3210mm) |
Undercarriage
| Loading Shovel Shoe Width | 24.02 in (610 mm) |
| Max Travel Speed | 2.55 mph (4.1 km/h) |
| Loading Shovel Operating Weight | 151016.66 lb (68500 kg) |
| Loading Shovel Ground Pressure | 15.9 psi (109.63 kPa) |
Engine
| Engine Make | 2238 |
| Engine Model | Cummins KT-1150-C450 |
| Gross Power | 410 hp (305.8 kw) |
| Displacement | 1150 cu in (18.9 L) |
| Aspiration | turbocharged |
Operational
| Fuel Capacity | 224.6 gal (850 L) |
| Hydraulic System Fluid Capacity | 118.9 gal (450 L) |
| Swing Speed | 4.3 rpm |
