| Ground Clearance | 3.61 ft in (1100 mm) |
| Track Gauge | 19.69 ft in (6000 mm) |
| Dig Height - Mono Boom | 64.64 ft in (19700 mm) |
| Digging Reach - Mono Boom | 66.28 ft in (20200 mm) |
| Dump Height - Mono Boom | 40.03 ft in (12200 mm) |
| Ground Level Reach - Mono Boom | 63.65 ft in (19400 mm) |
| Overall Width | 33.08 ft in (10080 mm) |
| Tailswing Radius | 26.09 ft in (7950 mm) |
| Track Length On Ground | 22.97 ft in (7000 mm) |
| Transport Height - Maximum | 28.22 ft in (8600 mm) |
| Transport Length | 491.93 in (12495 mm) |
| Undercarriage Overall Length | 30.68 ft in (9350 mm) |
| Dig Depth | 346.46 in (8800 mm) |
| Width Over Standard Tracks | 24.28 ft in (7400 mm) |
| Dig Depth - 2.44m 8 Ft Flat Bottom | 28.55 ft in (8700 mm) |
