Caterpillar E650
Browse All Caterpillar or Shovel Models
Contents:
Backhoe Boom / Stick 1
| Max Dig Depth | 28.88 ft in (8800 mm) |
| Max Vertical Wall Dig Depth | 24.28 ft in (7400 mm) |
| Max Cutting Height | 40.36 ft in (12300 mm) |
| Max Dump Height | 27.43 ft in (8360 mm) |
| Backhoe Boom / Stick | Stick 11'5" (3470mm) |
| Max Reach On Ground | 43.74 ft in (13330 mm) |
Dimensions
| Width Over Tracks | 11.46 ft in (3490 mm) |
| Height To Top Of Cab | 11.85 ft in (3610 mm) |
| Ground Clearance | 2.2 in (670 mm) |
| Length Of Tracks | 17.79 ft in (5420 mm) |
| Upper Structure Ground Clearance | 4.34 ft in (1320 mm) |
Loading Shovel
| Max Dig Reach | 32.16 ft in (9800 mm) |
| Max Dump Height | 24.25 ft in (7390 mm) |
| Max Cutting Height | 34.45 ft in (10500 mm) |
Undercarriage
| Loading Shovel Shoe Width | 24.02 in (610 mm) |
| Backhoe Ground Pressure - Shoe 2 | 12.8 psi (88.26 kPa) |
| Backhoe Shoe Width 3 | 35.83 in (910 mm) |
| Backhoe Ground Pressure - Shoe 1 | 15.65 psi (107.91 kPa) |
| Loading Shovel Ground Pressure | 16.5 psi (113.77 kPa) |
| Loading Shovel Operating Weight | 145505.11 lb (66000 kg) |
| Backhoe Shoe Width 2 | 29.93 in (760 mm) |
| Backhoe Shoe Width 1 | 24.02 in (610 mm) |
| Backhoe Operating Weight - Shoe 2 | 138009.39 lb (62600 kg) |
| Backhoe Ground Pressure - Shoe 3 | 10.8 psi (74.47 kPa) |
| Max Travel Speed | 2.86 mph (4.6 km/h) |
Engine
| Engine Make | 2251 |
| Engine Model | C S6B-TA |
| Gross Power | 375.5 hp (280 kw) |
| Displacement | 786 cu in (12.9 L) |
Operational
| Fuel Capacity | 165.2 gal (625 L) |
