Terex GS4096RT
Browse All Terex or Scissor Lift Models
Contents:
Dimensions
| Overall Length | 122.84 in (3120 mm) |
| Wheelbase | 7.52 ft in (2290 mm) |
| Overall Width | 5.75 ft in (1750 mm) |
| Height W/ Rails | 8.99 ft in (2740 mm) |
| Ground Clearance | 9.5 in (241.3 mm) |
| Gradeability | 35 % |
| Turning Radius - Outside | 15.1 ft in (4600 mm) |
| Turning Radius - Inside | 6.93 ft in (2110 mm) |
| Height W/O Rails | 6.83 ft in (2080 mm) |
Platform
| Max Platform Height | 40.3 ft in (12283.44 mm) |
| Deck Extension | 59.85 in (1520 mm) |
| Max Working Height | 46 ft in (14020.8 mm) |
| Platform Inner Length | 109.85 in (2790 mm) |
| Platform Inner Width | 63 in (1600 mm) |
| Max Platform Weight Capacity | 800.28 lb (363 kg) |
| Lower Time | 28 sec |
| Lift Time | 61 sec |
Engine
| Engine Model | Kubota D-1105 Tier 4f diesel |
| Gross Power | 24.8 hp (18.5 kw) |
| Fuel Type | Gas/LPG |
Operational
| Operating Weight | 10244.9 lb (4647 kg) |
| Fuel Capacity | 10.1 gal (37.9 L) |
| Hydraulic System Fluid Capacity | 18 gal (68.1 L) |
| Max Speed | 3.5 mph (5.6 km/h) |
| Tire Size | 12 x 26 |
| Tire Fill/Type | Rough terrain |
