Holland Lift B165 Combistar
Browse All Holland Lift or Scissor Lift Models
Contents:
Dimensions
| Overall Length | 15.88 in (4840 mm) |
| Wheelbase | 10.11 ft in (3080 mm) |
| Overall Width | 8.01 ft in (2440 mm) |
| Height W/ Rails | 11.13 ft in (3390 mm) |
| Ground Clearance | 6.5 in (165 mm) |
| Height W/O Rails | 8.6 ft in (2620 mm) |
Platform
| Max Platform Height | 54.14 ft in (16500 mm) |
| Deck Extension | 70.87 in (1800 mm) |
| Max Working Height | 60.7 ft in (18500 mm) |
| Max Platform Weight Capacity | 1433.01 lb (650 kg) |
| Lower Time | 48 sec |
| Platform Inner Length | 172.05 in (4370 mm) |
| Platform Inner Width | 90.56 in (2300 mm) |
| Lift Time | 72 sec |
Engine
| Engine Make | 2360 |
| Engine Model | 2L21C |
Operational
| Operating Weight | 23236.8 lb (10540 kg) |
| Max Speed | 2 mph (3.2 km/h) |
| Tire Size | 12x16.5 |
