Haulotte HS4388RTXL
Browse All Haulotte or Scissor Lift Models
Contents:
Dimensions
| Overall Length | 17.43 in (5309.62 mm) |
| Wheelbase | 9 ft in (2743.2 mm) |
| Overall Width | 7.42 ft in (2261.62 mm) |
| Height W/ Rails | 9.08 ft in (2767.59 mm) |
| Ground Clearance | 11 in (279.4 mm) |
| Height W/O Rails | 6.25 ft in (1905 mm) |
| Turning Radius | 20.33 ft in (6196.59 mm) |
Platform
| Max Platform Height | 42.67 ft in (13005.82 mm) |
| Deck Extension | 39 in (990.6 mm) |
| Max Working Height | 48.67 ft in (14834.62 mm) |
| Max Platform Weight Capacity | 1103 lb (500.32 kg) |
| Platform Inner Length | 287 in (7289.8 mm) |
| Platform Inner Width | 75 in (1905 mm) |
| Lower Time | 57 sec |
| Lift Time | 46 sec |
Engine
| Engine Make | 0 |
| Gross Power | 32.2 hp (24 kw) |
| Fuel Type | Diesel |
Operational
| Operating Weight | 14399 lb (6531.3 kg) |
| Fuel Capacity | 17 gal (64.4 L) |
| Hydraulic System Fluid Capacity | 26 gal (98.5 L) |
| Max Speed | 3.7 mph (6 km/h) |
| Tire Size | 10x16.5 |
| Tire Fill/Type | Foam |
