Terex RT200/200XL
Browse All Terex or Rough Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 30 ft in (9.15 m) |
| Max Height @ Max Raise Angle - No Jib | 94 ft in (28.66 m) |
| Max Elevating Angle | 76 degrees |
| Swing Speed | 3 rpm |
| Number Of Sections | 4 |
Dimensions
| Transport Length | 39.57 ft in (12060 mm) |
| Transport Width | 8.9 ft in (2710 mm) |
| Transport Height | 11 ft in (3350 mm) |
| Wheelbase | 11.16 in (3400 mm) |
| Ground Clearance | 1.61 ft in (490 mm) |
| Width W/ Outriggers Extended | 20.51 ft in (6250 mm) |
| Carrier/Base Length | 21.89 ft in (6670 m) |
Engine
| Engine Make | 2347 |
| Engine Model | 6BTA5.9 |
| Gross Power | 130 hp (97 kw) |
| Power Measured @ | 2500 rpm |
| Max Torque | 384 lb ft (520.7 Nm) |
| Torque Measured @ | 1200 rpm |
| Displacement | 359 cu in (5.9 L) |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 55930 lb (25369.5 kg) |
| Fuel Capacity | 50 gal (189.3 L) |
| Hydraulic System Fluid Capacity | 93.8 gal (355 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 102 amps |
| Tire Size | 20.5 x 25, 24 P.R. |
Transmission
| Transmission Type | Powershift Transmission |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 6 |
| Max Speed - Forward | 24.5 mph (39.5 km/h) |
