Terex RT100
Browse All Terex or Rough Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 38.06 ft in (11.6 m) |
| Max Height @ Max Raise Angle - No Jib | 173.89 ft in (53 m) |
| Max Elevating Angle | 78 degrees |
| Number Of Sections | 6 |
Dimensions
| Transport Length | 45.43 ft in (13847 mm) |
| Transport Width | 10.82 ft in (3296 mm) |
| Transport Height | 12.96 ft in (3950 mm) |
| Wheelbase | 175.2 in (4450 mm) |
| Ground Clearance | 2.11 ft in (642 mm) |
| Width W/ Outriggers Extended | 26.25 ft in (8000 mm) |
| Carrier/Base Length | 29442.26 ft in (8974 m) |
| Upper Structure Tail Swing Radius | 15.55 ft in (4738 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | Cummins |
| Engine Model | QSB6.7 |
| Gross Power | 260.2 hp (194 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 728 lb ft (987 Nm) |
| Torque Measured @ | 1500 rpm |
Operational
| Fuel Capacity | 79.3 gal (300 L) |
| Operating Voltage | 24 V |
| Tire Size | 29.5 R25 |
