Grove RT880
Browse All Grove or Rough Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 36 ft in (10.98 m) |
| Max Height @ Max Raise Angle - No Jib | 114 ft in (34.75 m) |
| Min Operating Radius | 10 ft in (3.05 m) |
| Max Elevating Angle | 80 degrees |
| Max Operating Radius | 100 ft in (30.48 m) |
| Swing Speed | 2 rpm |
| Max Lift Capacity | 160000 lb (72574.79 kg) |
| Number Of Sections | 4 |
Dimensions
| Transport Length | 47.42 ft in (14453 mm) |
| Transport Width | 12.09 ft in (3683 mm) |
| Transport Height | 12.8 ft in (3899 mm) |
| Wheelbase | 14.17 in (4318 mm) |
| Width W/ Outriggers Extended | 26.55 ft in (8090 mm) |
| Carrier/Base Length | 27.92 ft in (8509 m) |
| Upper Structure Tail Swing Radius | 14.29 ft in (4353 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | Cummins |
| Engine Model | 6CTA 8.3L |
| Gross Power | 249.5 hp (186 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 794.4 lb ft (1077 Nm) |
| Torque Measured @ | 1500 rpm |
| Displacement | 506.5 cu in (8.3 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 109874 lb (49838 kg) |
| Fuel Capacity | 100 gal (378.6 L) |
| Hydraulic System Fluid Capacity | 225.1 gal (852 L) |
| Operating Voltage | 12 V |
| Tire Size | 29.5x25-28PR |
Transmission
| Transmission Type | full powershift |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 6 |
| Max Speed - Forward | 18.8 mph (30.1 km/h) |
