Terex MT5500AC
Browse All Terex or Rock Truck Models
Contents:
Dimensions
| Overall Length | 48.5 ft in (14780 mm) |
| Overall Width | 30.19 ft in (9200 mm) |
| Overall Height | 25.17 ft in (7670 mm) |
Dump
| Dump Angle | 45 degrees |
| Raise Time | 20 sec |
| Load Capacity - Heaped | 285.14 yd3 (218 m3) |
| Lower Time | 20 sec |
| Rated Payload | 718706.93 lb (326000 kg) |
Engine
| Number Of Cylinders | 20 |
| Engine Make | 2350 |
| Engine Model | 20V4000 |
| Net Power | 3649 hp (2721 kw) |
Operational
| Tire Size | 55/80R63 |
Transmission
| Transmission Type | AC Drive |
| Max Speed | 40.4 mph (65 km/h) |
Weights
| Empty Weight | 477918.1 lb (216780 kg) |
