Dresser 510E
Browse All Dresser or Rock Truck Models
Contents:
Dimensions
| Overall Length | 37.33 ft in (11378.19 mm) |
| Overall Width | 20.92 ft in (6376.42 mm) |
| Overall Height | 35.5 ft in (10820.4 mm) |
| Wheelbase | 16.83 ft in (5129.79 mm) |
| Ground Clearance | 2.08 ft in (633.99 mm) |
| Dump Height | 16.83 ft in (5129.79 mm) |
| Dump Ground Clearance | 4.92 ft in (1499.62 mm) |
Dump
| Dump Angle | 45 degrees |
| Load Capacity - Struck | 70.63 yd3 (54 m3) |
| Load Capacity - Heaped | 100.72 yd3 (77 m3) |
| Rated Payload | 299828.66 lb (136000 kg) |
| Lower Time | 13 sec |
| Raise Time | 22 sec |
Engine
| Number Of Cylinders | 12 |
| Engine Make | 2350 |
| Engine Model | 12V-149TIB |
| Gross Power | 1350 hp (1006.7 kw) |
| Net Power | 1279 hp (953.8 kw) |
| Power Measured @ | 1900 rpm |
Operational
| Fuel Capacity | 700 gal (2649.8 L) |
| Cooling System Fluid Capacity | 60 gal (227.2 L) |
| Brake/Hoist System Fluid Capacity | 34 gal (128.8 L) |
| Hydraulic System Fluid Capacity | 108 gal (408.9 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 175 amps |
| Tire Size | 33.00 51 |
Transmission
| Max Speed | 33.4 mph (53.8 km/h) |
Weights
| Empty Weight | 210100 lb (95299.8 kg) |
| Loaded Weight | 510000 lb (231332.2 kg) |
