New Holland C175
Browse All New Holland or Multi Terrain Loader Models
Contents:
Dimensions
| Width Over Tracks | 5.94 ft in (1810 mm) |
| Height To Top Of Cab | 6.3 ft in (1920 mm) |
| Ground Clearance | 7.88 in (200 mm) |
| Clearance At Max Lift And Dump | 12.14 ft in (3700 mm) |
| Reach At Max Lift And Dump | 2.56 ft in (780 mm) |
| Length With Bucket | 10.8 ft in (3290 mm) |
| Turning Radius From Center - Inc Bucket | 78.15 in (1985 mm) |
Undercarriage
| Length Of Track On Ground | 4.73 ft in (1440 mm) |
| Track Gauge | 4.89 ft in (1490 mm) |
| Number Of Track Rollers Per Side | 3 |
| Width Of Track | 12.6 in (320 mm) |
| Ground Pressure | 5.3 psi (0.26 kPa) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2249 |
| Engine Model | N844LT |
| Gross Power | 60 hp (45 kw) |
| Net Power | 56 hp (42 kw) |
| Power Measured @ | 2900 rpm |
| Peak Torque | 128 lb ft (173 Nm) |
| Torque Measured @ | 1700 rpm |
| Displacement | 135 cu in (2.2 L) |
| Aspiration | Turbochaged |
Operational
| Operating Weight | 7535 lb (3418 kg) |
| Cooling System Fluid Capacity | 4.5 gal (17 L) |
| Fuel Capacity | 14.4 gal (54.5 L) |
| Engine Oil Capacity | 2.1 gal (8 L) |
| Hydraulic System Fluid Capacity | 8.6 gal (32.5 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 amps |
| Max Speed - Low Range | 5.6 mph (9 km/h) |
| Max Speed - High Range | 7.4 mph (12 km/h) |
Loader
| Breakout Force | 4312 lb (1956 kg) |
| Operating Load | 2200 lb (998 kg) |
| Tipping Angle | 6300 degrees |
| Bucket Capacity | 0.7 yd3 (0.5 m3) |
Hydraulic
| Pump Type | Gear Type |
| Pump Flow | 17.2 gal/min (65.2 L/min) |
| Relief Valve Pressure | 2600 psi (17926.4 kPa) |
