Volvo EW 180 D
Browse All Volvo or Mobile Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Cutting Height | 33.34 ft in (10160 mm) |
| Max Digging Depth | 19.62 ft in (5980 mm) |
| Max Digging Reach | 30.98 ft in (9440 mm) |
| Min - Front Slew Radius | 9.03 ft in (2750 mm) |
| Boom/Stick Option (Hex) 1 | MoonBoom 5,2 mm,(Ft,in-17,1),Arm 245m,(Ft,in-8,0) |
| Max Vertical Wall Digging Depth | 16.21 ft in (4940 mm) |
| Max.Dumping Height | 23.33 ft in (7110 mm) |
| Max Digging Reach On Ground | 30.35 ft in (9250 mm) |
Boom/Stick Option (Hex) 2
| Max Cutting Height | 33.6 ft in (10240 mm) |
| Max Digging Depth | 20.12 ft in (6130 mm) |
| Max.Dumping Height | 23.59 ft in (7190 mm) |
| Min - Front Slew Radius | 9.03 ft in (2750 mm) |
| Max Digging Reach | 31.4 ft in (9570 mm) |
| Boom/Stick Option (Hex) 2 | MoonBoom 5,2 mm,(Ft,in-17,1),Arm 26m,(Ft,in-8,6) |
| Max Vertical Wall Digging Depth | 15.2 ft in (4630 mm) |
| Max Digging Reach On Ground | 30.78 ft in (9380 mm) |
Boom/Stick Option (Hex) 3
| Max Cutting Height | 34.49 ft in (10510 mm) |
| Max Digging Depth | 21.43 ft in (6530 mm) |
| Max Vertical Wall Digging Depth | 16.38 ft in (4990 mm) |
| Max Digging Reach | 32.65 ft in (9950 mm) |
| Min - Front Slew Radius | 9.29 ft in (2830 mm) |
| Max.Dumping Height | 24.51 ft in (7470 mm) |
| Boom/Stick Option (Hex) 3 | MoonBoom 5,2 mm,(Ft,in-17,1),Arm 30m,(Ft,in-9,10) |
| Max Digging Reach On Ground | 32.06 ft in (9770 mm) |
Boom/Stick Option (Hex) 4
| Max Cutting Height | 13.46 ft in (4100 mm) |
| Max Vertical Wall Dig Depth | 18.31 ft in (5580 mm) |
| Max Digging Depth | 19 ft in (5790 mm) |
| Min - Front Slew Radius | 10.57 ft in (3220 mm) |
| Boom/Stick Option (Hex) 4 | 2-piece boom 5,3M (17,5 ft-in),Arm 245m,(8,0,(ft-in) |
| Max Digging Reach | 30.39 ft in (9260 mm) |
| Max Digging Reach On Ground | 29.76 ft in (9070 mm) |
| Max.Dumping Height | 30.02 ft in (9150 mm) |
Boom/Stick Option (Hex) 5
| Max Cutting Height | 30.16 ft in (9190 mm) |
| Max Vertical Wall Dig Depth | 13.78 ft in (4200 mm) |
| Max Digging Depth | 19.49 ft in (5940 mm) |
| Max - Dumping Height | 20.97 ft in (6390 mm) |
| Max - Digging Reach On Ground | 30.16 ft in (9190 mm) |
| Max - Digging Reach | 30.81 ft in (9390 mm) |
| Boom/Stick Option (Hex) 5 | 2-piece boom 5,3M (17,5 ft-in),Arm 26m,(8,6,(ft-in) |
| Min - Front Slew Radius | 10.5 ft in (3200 mm) |
Boom/Stick Option (Hex) 6
| Max Cutting Height | 30.78 ft in (9380 mm) |
| Max Vertical Wall Dig Depth | 15.03 ft in (4580 mm) |
| Max Digging Depth | 20.81 ft in (6340 mm) |
| Max - Digging Reach | 32.03 ft in (9760 mm) |
| Max - Dumping Height | 21.63 ft in (6590 mm) |
| Max - Digging Reach On Ground | 31.4 ft in (9570 mm) |
| Boom/Stick Option (Hex) 6 | 2-piece boom 5,3M (17,5 ft-in),Arm 30m,(9,10,(ft-in) |
| Min - Front Swing Radius | 10.47 ft in (3190 mm) |
Dimensions
| Wheelbase | 8.7 ft in (2650 mm) |
| Tail Swing Radius | 8.37 ft in (2550 mm) |
| Overall Width | 100 in (2540 mm) |
| Ground Clearance | 1.1 ft in (333 mm) |
| Height To Top Of Cab | 21.89 ft in (6670 mm) |
| Overall Length | 29.11 ft in (8870 mm) |
| Counterweight Clearance | 4.2 ft in (1280 mm) |
Speeds
| Speed -On Road | 22 mph (35.5 km/h) |
| Speed -Off Road | 5.5 mph (8.9 km/h) |
| Creep | 2.3 mph (3.8 km/h) |
| Min Turning Radius | 82.1 ft in (25 m) |
Electrical System
| Battery Capacity | 100 Ah |
| Alternator Rating | 3360 W |
| Alternator | 28/110 V/Ah |
| Voltage | 24 V V (deletedelete) |
| Batteries | 2 X 12 V |
Engine
| Max Power | 2000 rpm |
| Number Of Cylinders | 6 |
| Engine Model | D6H |
| Gross Power | 173 hp (129.1 kw) |
| Net Power | 169 hp (126.1 kw) |
| Displacement | 347.9 cu in (5.7 L) |
| Torque Measured @ | 1500 rpm |
| Net Torque | 559.1 lb ft (758 Nm) |
| Bore | 3.9 in (98 mm) |
| Stroke | 5 in (126 mm) |
Capacities
| Front Axle | 579.8 cu in (9.5 L) |
| Hydraulic Tank - Total System | 79.3 gal (300 L) |
| Fuel Tank | 88.5 gal (335 L) |
| Hydraulic Tank | 43.6 gal (165 L) |
| Rear Axle | 3.4 gal (12.5 L) |
| Transmission | 0.7 gal (2.5 L) |
| Final Drive | 2.7 gal (10 L) |
| Engine Oil | 6.7 gal (25 L) |
| Engine Coolant | 8.8 gal (33 L) |
Hydraulic System
| Maximum Flow -Servo Pump, Low Noise Gear Pump | 4.1 gal/min (15.2 L/min) |
| Main Pump- Low Noise Axial Piston Pump-Max Flow | 9.6 gal/min (36.1 L/min) |
| Implement | 5440 psi (37507.5 kPa) |
| Travel Circuit | 5440 psi (37507.5 kPa) |
| Pilot Circuit | 490 psi (3378.5 kPa) |
| Steering Pump | 2.7 gal/min (10 L/min) |
