Liebherr A954BHD
Browse All Liebherr or Mobile Excavator Models
Contents:
Boom/Stick Option (Mex) 1
| Shipping Length Of Unit | 42.66 ft in (13000 mm) |
| Shipping Height Of Unit | 13.03 ft in (3970 mm) |
| Boom/Stick Option (Mex) 1 | Boom 8800mm / Stick 7000 |
Boom/Stick Option (Mex) 2
| Shipping Length Of Unit | 47.58 ft in (14500 mm) |
| Shipping Height Of Unit | 13.03 ft in (3970 mm) |
| Boom/Stick Option (Mex) 2 | Boom 10300mm / Stick 9500 |
Dimensions
| Wheelbase | 11.82 ft in (3600 mm) |
| Tail Swing Radius | 12.57 ft in (3830 mm) |
| Overall Width | 10.73 in (3270 mm) |
| Ground Clearance | 1.66 ft in (505 mm) |
| Overall Width - Outriggers Down | 18.67 ft in (5690 mm) |
| Height To Top Of Cab | 13.03 ft in (3970 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2245 |
| Engine Model | D 926 TI-E |
| Gross Power | 302 hp (225.3 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 610.3 cu in (10 L) |
| Aspiration | turbocharged and aftercooled |
Operational
| Fuel Capacity | 186.6 gal (706 L) |
| Operating Weight | 138891.3 lb (63000 kg) |
| Hydraulic System Fluid Capacity | 211.4 gal (800 L) |
| Operational Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
| Hydraulic System Relief Valve Pressure | 5076.4 psi (35000 kPa) |
| Hydraulic Pump Type | variable displacement swash plate |
| Hydraulic Pump Flow Capacity | 92.5 gal/min (350 L/min) |
Swing Mechanism
| Swing Speed | 6.2 rpm |
| Swing Torque | 115059.7 lb ft (156000 Nm) |
Transmission
| Max Travel Speed | 6.3 mph (10 km/h) |
