Pel-Job EB450
Browse All Pel-Job or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 16.18 ft in (4930 mm) |
| Max Cutting Height | 16.18 ft in (4930 mm) |
| Shipping Height Of Unit | 8.24 ft in (2510 mm) |
| Max Loading Height | 11.95 ft in (3640 mm) |
| Max Reach Along Ground | 17.33 ft in (5280 mm) |
| Max Vertical Wall Digging Depth | 7.58 ft in (2310 mm) |
| Max Digging Depth | 10.9 ft in (3320 mm) |
| Boom/Stick Option (Hex) 1 | dipper 1400mm |
Boom/Stick Option (Hex) 2
| Max Cutting Height | 16.77 ft in (5110 mm) |
| Shipping Length Of Unit | 16.18 ft in (4930 mm) |
| Max Loading Height | 12.5 ft in (3810 mm) |
| Shipping Height Of Unit | 8.24 ft in (2510 mm) |
| Max Reach Along Ground | 18.28 ft in (5570 mm) |
| Max Vertical Wall Digging Depth | 8.37 ft in (2550 mm) |
| Max Digging Depth | 11.88 ft in (3620 mm) |
| Boom/Stick Option (Hex) 2 | dipper 1700mm |
Dimensions
| Width To Outside Of Tracks | 5.91 ft in (1800 mm) |
| Length Of Track On Ground | 5.81 ft in (1770 mm) |
| Ground Clearance | 1.05 ft in (320 mm) |
| Height To Top Of Cab | 8.24 ft in (2510 mm) |
| Tail Swing Radius | 4.47 ft in (1360 mm) |
| Removal Counterweight Clearance | 2.14 ft in (650 mm) |
Undercarriage
| Shoe Size | 15.75 in (400 mm) |
| Max Travel Speed | 2.68 mph (4.3 km/h) |
| Number Of Track Rollers Per Side | 4 |
| Ground Pressure | 3.69 psi (25.45 kPa) |
| Number Of Carrier Rollers Per Side | 1 |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2251 |
| Engine Model | K4N |
| Gross Power | 42 hp (31.4 kw) |
| Net Power | 37 hp (27.6 kw) |
| Power Measured @ | 2600 rpm |
| Displacement | 139.8 cu in (2.3 L) |
| Max Torque | 101.1 lb ft (137 Nm) |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 9671.7 lb (4387 kg) |
| Fuel Capacity | 17.5 gal (66 L) |
| Cooling System Fluid Capacity | 2.2 gal (8 L) |
| Hydraulic System Fluid Capacity | 16.4 gal (62 L) |
| Engine Oil Capacity | 2.1 gal (7.7 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 amps |
| Hydraulic System Relief Valve Pressure | 3771 psi (26000 kPa) |
| Hydraulic Pump Flow Capacity | 26.2 gal/min (99 L/min) |
Swing Mechanism
| Swing Speed | 10 rpm |
Buckets
| Reference Bucket Capacity | 0.2 yd3 (0.1 m3) |
| Minimum Bucket Capacity | 0.1 yd3 (0.1 m3) |
| Maximum Bucket Capacity | 0.3 yd3 (0.2 m3) |
