New Holland E22SR
Browse All New Holland or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 12.54 ft in (3820 mm) |
| Max Loading Height | 9.49 ft in (2890 mm) |
| Max Reach Along Ground | 12.67 ft in (3860 mm) |
| Max Digging Depth | 8.8 ft in (2680 mm) |
| Boom/Stick Option (Hex) 1 | standard |
Dimensions
| Width To Outside Of Tracks | 4.76 ft in (1450 mm) |
| Length Of Track On Ground | 4.57 ft in (1390 mm) |
| Ground Clearance | 0.4 ft in (120 mm) |
| Tail Swing Radius | 2.47 ft in (750 mm) |
Undercarriage
| Shoe Size | 9.85 in (250 mm) |
Engine
| Engine Make | 2348 |
| Gross Power | 14.8 hp (11 kw) |
Operational
| Operating Weight | 5125.8 lb (2325 kg) |
| Hydraulic System Relief Valve Pressure | 3335.9 psi (23000 kPa) |
| Hydraulic Pump Flow Capacity | 10.6 gal/min (40 L/min) |
