Komatsu PC95MR-2
Browse All Komatsu or Midi Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 20.18 ft in (6150 mm) |
| Shipping Height Of Unit | 8.86 ft in (2700 mm) |
| Max Cutting Height | 20 ft in (6095 mm) |
| Max Loading Height | 13.53 ft in (4125 mm) |
| Max Reach Along Ground | 21.7 ft in (6615 mm) |
| Max Digging Depth | 12.25 ft in (3735 mm) |
| Boom/Stick Option (Hex) 1 | Monoboom / Stick - 1600mm |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 20.18 ft in (6150 mm) |
| Shipping Height Of Unit | 8.86 ft in (2700 mm) |
| Max Cutting Height | 20.49 ft in (6245 mm) |
| Max Loading Height | 14.03 ft in (4275 mm) |
| Max Reach Along Ground | 22.47 ft in (6850 mm) |
| Max Digging Depth | 13.07 ft in (3985 mm) |
| Boom/Stick Option (Hex) 2 | Monoboom / Stick - 1850mm |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 20.18 ft in (6150 mm) |
| Shipping Height Of Unit | 8.86 ft in (2700 mm) |
| Max Cutting Height | 21.39 ft in (6520 mm) |
| Max Loading Height | 14.93 ft in (4550 mm) |
| Max Reach Along Ground | 23.87 ft in (7275 mm) |
| Max Digging Depth | 14.6 ft in (4450 mm) |
| Boom/Stick Option (Hex) 3 | Monoboom / Stick - 2300mm |
Dimensions
| Width To Outside Of Tracks | 7.22 ft in (2200 mm) |
| Length Of Track On Ground | 7.68 ft in (2340 mm) |
| Height To Top Of Cab | 8.86 ft in (2700 mm) |
| Tail Swing Radius | 4.95 ft in (1510 mm) |
| Removal Counterweight Clearance | 2.54 ft in (775 mm) |
Undercarriage
| Shoe Size | 17.72 in (450 mm) |
| Track Gauge | 5.9 ft in (1800 mm) |
| Number Of Track Rollers Per Side | 6 |
| Number Of Carrier Rollers Per Side | 1 |
| Max Travel Speed | 3.11 mph (5 km/h) |
| Number Of Shoes Per Side | 44 |
Engine
| Engine Make | 2238 |
| Engine Model | 4D106-1FB |
| Net Power | 84 hp (62.7 kw) |
| Displacement | 269.3 cu in (4.5 L) |
| Max Torque | 228.7 lb ft (310 Nm) |
Operational
| Operating Weight | 19290.5 lb (8750 kg) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 80 amps |
| Hydraulic Pump Flow Capacity | 47.6 gal/min (180 L/min) |
Swing Mechanism
| Swing Speed | 10.2 rpm |
Buckets
| Reference Bucket Capacity | 0.4 yd3 (0.3 m3) |
| Minimum Bucket Capacity | 0.2 yd3 (0.1 m3) |
| Maximum Bucket Capacity | 0.5 yd3 (0.4 m3) |
