Airman AX50U-4
Browse All Airman or Midi Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 17.92 ft in (5460 mm) |
| Shipping Height Of Unit | 8.37 ft in (2550 mm) |
| Max Loading Height | 13.46 ft in (4100 mm) |
| Max Reach Along Ground | 19.69 ft in (6000 mm) |
| Max Vertical Wall Digging Depth | 9.36 ft in (2850 mm) |
| Max Digging Depth | 11.82 ft in (3600 mm) |
Dimensions
| Width To Outside Of Tracks | 6.57 ft in (2000 mm) |
| Length Of Track On Ground | 6.57 ft in (2000 mm) |
| Ground Clearance | 1.1 ft in (335 mm) |
| Tail Swing Radius | 3.29 ft in (1000 mm) |
Undercarriage
| Shoe Size | 15.75 in (400 mm) |
| Max Travel Speed | 2.8 mph (4.5 km/h) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2348 |
| Engine Model | 4TNV88 |
| Gross Power | 40 hp (29.8 kw) |
| Power Measured @ | 2500 rpm |
| Displacement | 133.6 cu in (2.2 L) |
Operational
| Operating Weight | 10427.9 lb (4730 kg) |
| Hydraulic System Relief Valve Pressure | 3481 psi (24000 kPa) |
| Hydraulic Pump Flow Capacity | 33.1 gal/min (125 L/min) |
Buckets
| Reference Bucket Capacity | 0.3 yd3 (0.2 m3) |
