Kubota M7-171P-PS
Browse All Kubota or MFWD Tractor Models
Contents:
Dimensions
| Overall Length | 187.8 in (4770 mm) |
| Wheelbase | 8.93 ft in (2720 mm) |
| Overall Width | 9.17 ft in (2794 mm) |
| Height With Rops | 9.95 ft in (3030 mm) |
Engine
| Battery | 174 Ah (20 hr) / 1400A |
| Number Of Cylinders | 4 |
| Engine Make | Kubota |
| Engine Type | Direct Injection |
| Gross Power | 168 hp (125.3 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 374 cu in (6.2 L) |
| Aspiration | Turbocharger with intercooler |
| Bore | 4.7 in (118 mm) |
| Stroke | 5.6 in (140 mm) |
| Alternator | 200 amps |
| Model Name | M7-171 |
Operational
| Def Tank Capacity | 10 gal (37.9 L) |
| Operating Weight | 15097.3 lb (6848 kg) |
| Tires | Front - 14.9 R24, Rear - 18.4 R38 |
| 3 Point Hitch Type | Telescopic lower link, Category 3 / 3N |
| 3 Point Hitch Lift Capacity @ 24 Inches | 11794.8 lb (5350 kg) |
Power Take-Off(Pto)
| Pto Horsepower | 140 hp (104.4 kw) |
| Power Take-Off(Pto) Type | 110” bar axle |
Transmission
| Transmission Type | CVT |
| Number Of Forward Gears | 24 |
| Number Of Reverse Gears | 24 |
| Max Speed | 25 mph (40.3 km/h) |
Hydraulic System
| Pump Flow Capacity | 29 gal/min (109.8 L/min) |
| Number Of Remote Control Valves | Maximum 5 valves |
