Kubota B2301HSD
Browse All Kubota or MFWD Tractor Models
Contents:
Dimensions
| Overall Length | 93.71 in (2380 mm) |
| Wheelbase | 5.12 ft in (1560 mm) |
| Overall Width | 3.78 ft in (1150 mm) |
| Ground Clearance | 12.01 in (305 mm) |
| Height With Rops | 6.99 ft in (2130 mm) |
| Rear Wheel Tread Width - Min | 82.68 in (2100 mm) |
Engine
| Number Of Cylinders | 3 |
| Engine Make | Kubota |
| Engine Model | D1005 |
| Engine Type | E-TVCS, liquid cooled |
| Gross Power | 22 hp (16.5 kw) |
| Air Cleaner | Dual paper element |
| Pto Power | 17.5 hp (13.1 kw) |
| Power Measured @ | 2800 rpm |
| Displacement | 61.1 cu in (1.1 L) |
| Aspiration | Turbocharger with intercooler |
| Bore | 3 in (76 mm) |
| Stroke | 2.9 in (73.6 mm) |
| Model Name | B2301HSD |
Capacities
| Cooling System | 1.1 gal (3.8 L) |
| Fuel Tank | 6.1 gal (23.1 L) |
| Transmission | 4 gal (15.2 L) |
| Engine Oil | 0.9 gal (3.1 L) |
Operational
| Operating Weight | 1565.3 lb (710 kg) |
| Tires | Front - 6-12, Rear - 9.5-16 |
| 3 Point Hitch Type | Category I |
| 3 Point Hitch Lift Capacity @ 24 Inches | 1411 lb (640 kg) |
Power Take-Off(Pto)
| Mid-Pto Speed | 2500 rpm |
| Power Take-Off(Pto) Type | Independent |
Transmission
| Brakes | Multi-plate wet disc |
| Transmission Type | HST (3 ranges) |
| Max Speed - Reverse | 8.9 mph (14.4 km/h) |
| Max Speed - Forward | 11.9 mph (19.2 km/h) |
Hydraulic System
| Hydraulic System Type | Open center |
| Pump Type | Dual pump |
| Pump Flow Capacity | 8.3 gal/min (31.5 L/min) |
| Number Of Remote Control Valves | Position control valve |
