John Deere Row-Crop Tractors _ 8245R _ JD
Browse All John Deere or MFWD Tractor Models
Contents:
Dimensions
| Approx. Ship Wgt, Lb (Kg) Open; Cab | MFWD/PST with 625-kg (1378-lb) inner weights, front weight support, Cat3 hitch with QC, 113.6 L (30 gal.) fuel, 480/80R46 rear duals, 420/90R30 fronts: 12,680 kg; 27,953 lb ILS/IVT with 625-kg (1378-lb) inner weights,front weight support, Cat4 hitch with QC, 113.6 L (30 gal.) fuel, 480/80R50 rear duals, 420/85R34 front duals: 15,009 kg; 33,091 lb.MFWD/PST with: Inner weights: 625 kg 1378 lb front weight support/Cat3 hitch with QC/Fuel 113.6 L 30 gal. 480/80R46 duals/420/90R30 fronts 12,498 kg 27,553 lb |
| Front Axle Clearance, In. (Mm) | 1300 MFWD: 1524-2235 mm 60-88 in. 1500 MFWD/ILS: 1524-3657 mm 60-144 in.MFWD: 686 mm 27 in. ILS: 590 mm 23.2 in. |
| Limited Slip Differential | Limited slip or hydraulic lock differential available |
| Wheelbase, In. (Mm) | MFWD: 3080 mm 121.3 in. ILS: 3050 mm 120.1 in. |
Engine
| Engine Manufacturer | John Deere |
| Family | 9.0L: EJDXL09.0301 |
| Cylinder Liners | Wet |
| Fuel Tank Capacity | Standard With G47/48 tires: 645 L 170.4 U.S. gal. With G49 tires: 686 L 181.2 U.S. gal. |
| Displacement | 6 cylinders/9.0 L 549 cu in. |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series |
Power Take-Off(Pto)
| Standard | 45 mm (1.75 in.), 20 spline, 1000 rpm |
| Optional | "45 mm (1.75 in.), 20 spline, 1000 rpm and 1000E economy rpm, in-cab shiftable 45 mm (1.75 in.), 20 spline, 1000 rpm, capable of 35 mm (1.375 in.), 6/21 spline, 540/1000 rpm" |
| Pto Actuation | Electrohydraulic |
| Pto Speeds @ Engine Rpm | 16-speed PowerShift: 1000 PTO rpm @ 2003 engine rpm, 1000 ECO PTO rpm @ 1596 engine rpm, and 540 PTO rpm @ 1817 engine rpm IVT: 1000 PTO rpm @ 2000 engine rpm, 1000 ECO PTO @ 1594 engine rpm, and 540 PTO rpm @ 1814 engine rpm e23: 1000 PTO rpm @ 1995 engine rpm, 1000 ECO PTO @ 1590 engine rpm, and 540 PTO rpm @ 1810 engine rpm |
Performance
| Advertised Pto | "At @ 2100 per SAE: 149 PTO hp 200 hp" |
| Advertised Engine Hp (Kw) @ Rated Speed | "At 2100 per 97/68EC PS: 180 kW 245 hp" |
Transmission
| Creeper | IVT |
| Reverser | Left-hand or Right-hand (PowerShift RH only) |
| On-The-Go Shifting (Yes/No/Partial) | Yes |
| Std. Transmission; Forward/Reverse | 16-speed PowerShift; 16/5 |
| Opt. Transmission; Forward/Reverse | e23; 23/11 (42 or 50) km/h |
| Clutch; Wet/Dry | Wet |
Tires
| Mfwd | Front 420/90R30Rear 480/80R46 |
Hydraulic
| Remote Control Valves Available | Standard: four Optional: five or six 2 Front SCV option |
| Hitch Draft Control Load Sense Type | Electronic |
| Hitch Lift Cap | Standard Cat 3/3N: 6350 kg 14,000 lbOptional Cat 3/3N: 8391 kg 18,500 lb Cat 4N/3: 9072 kg 20,000 lb |
| Sensing Type | Electrohydraulic |
| Joystick Scv Control | Electrohydraulic optional |
| Hydraulic Type | Closed-center, pressure/flow compensated |
| Hitch Category (Sae Designation) | Standard: Cat 3/3N Optional: Cat 4N/3 |
| Pump Rated Output, Gpm (L/Min.) | Standard 227.1 L/min 60 gpmOptional 321 L/min 85 gpm |
| Maximum Operating Pressure, Psi (Kpa) | 20,400 (+ or - 300) kPa 2958 psi |
| Rated Flow @ One Scv, Gpm (L/Min.) 1 | Rear: 0.5 in. SCV: 132 L/min 35 gpm Rear: 0.75 in. SCV: 153 L/min 40.5 gpm Front SCV: 96 L/min 25 gpm |
Final Drive
| Final Drive Type | Inboard planetary |
| Differential Controls | Electrohydraulic |
| Availability | Front YesFront & Rear Yes Yes |
| Engage On-The-Go Rear Differential Lock | Yes |
| Axle Type | Bar axle, rack and pinion |
| Brakes, Type And Control | Hydraulic wet disc |
Operator Station
| Cab | Doors LHPlatform - Flat/Straddle FlatSeat Suspension System Standard: air Optional: active seat Optional: Cab suspension with air seat |
| Rollover Protective Structure, Oos | Gearshift Location - Console/Floor CommandARM |
