Case 480D
Browse All Case or Loader Backhoe Models
Contents:
Backhoe
| Load Height - Std | 8.4 ft in (2560 mm) |
| Reach From Swivel - Std | 15.72 ft in (4790 mm) |
| Dig Depth - Std | 12.01 ft in (3660 mm) |
| Load Height - Ext | 8.7 ft in (2650 mm) |
| Dig Depth - Ext | 15.13 ft in (4610 mm) |
| Bucket Dig Force - Ext | 7747.05 lb (3514 kg) |
| Bucket Dig Force - Std | 7597.13 lb (3446 kg) |
| Reach From Swivel - Ext | 18.67 ft in (5690 mm) |
Dimensions
| Transport Length | 10.5 ft in (3200 mm) |
| Transport Width | 6.93 ft in (2110 mm) |
| Transport Height | 10.08 ft in (3070 mm) |
| Wheelbase | 6.67 ft in (2030 mm) |
| Ground Clearance | 1.05 ft in (320 mm) |
| Height To Top Of Suspended Cab | 8.37 ft in (2550 mm) |
| Rear Tread Range | 66.15 in (1680 mm) |
| Shipping Weight | 5282.28 lb (2396 kg) |
| Front Wheel Tread Width | 61.82 in (1570 mm) |
Loader
| Clearance At Max Dump Height | 8.73 ft in (2660 mm) |
| Reach At Max Dump Height | 2.24 ft in (680 mm) |
| Bucket Breakout Force | 5700 lb (25.36 kN) |
| Bucket Width | 63.78 in (1620 mm) |
| Lift Capacity At Full Height | 3000 lb (1360.78 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | J.I. Case |
| Engine Model | G188D |
| Gross Power | 52 hp (38.8 kw) |
| Net Power | 47 hp (35.1 kw) |
| Power Measured @ | 2100 rpm |
| Torque Measured @ | 1400 rpm |
| Net Max Torque | 138 lb ft (187.2 Nm) |
| Displacement | 189.2 cu in (3.1 L) |
| Bore | 3.9 in (97 mm) |
| Stroke | 4.2 in (105 mm) |
Operational
| Fuel Capacity | 23.5 gal (89 L) |
| Max Weight | 9302 lb (4219.4 kg) |
| Hydraulic System Fluid Capacity | 10.8 gal (40.9 L) |
| Oil System Fluid Capacity | 1.8 gal (6.6 L) |
| Cooling System Fluid Capacity | 3.5 gal (13.2 L) |
| Tire Size Front - 2wd / 4wd | 7.50x16 |
| Rear Tires Size 2wd/4wd | 14.9x24 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 39 amps |
| Axle Load - Front | 9000 lb (4082.4 kg) |
| Axle Load - Rear | 13500 lb (6123.5 kg) |
Transmission
| Transmission Type | Power shuttle |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 20.9 mph (33.5 km/h) |
| Max Speed Reverse | 18.3 mph (29.3 km/h) |
Hydraulic
| Pump Flow Capacity | 23.9 gal/min (90.5 L/min) |
