Terex MAC 25
Browse All Terex or Hydraulic Truck Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 26.25 ft in (8 m) |
| Max Height @ Max Raise Angle - No Jib | 62.34 ft in (19 m) |
| Min Working Radius | 4.63 ft in (1.41 m) |
| Max Working Radius | 51.55 ft in (15.71 m) |
| Max Elevating Angle | 65 degrees |
| Max Lift Capacity | 55115.57 lb (25000 kg) |
| Number Of Sections | 4 |
Dimensions
| Transport Length | 32.76 ft in (9985 mm) |
| Transport Width | 8.93 ft in (2720 mm) |
| Transport Height | 10.09 ft in (3075 mm) |
| Ground Clearance | 1.24 ft in (375 mm) |
| Carrier Length | 23.48 ft in (7155 mm) |
Carrier Engine
| Make | Terex |
| Model | OM 906 LA |
| Gross Power | 275 hp (205.1 kw) |
| Power Measured @ | 2800 rpm |
| Max Torque | 811.4 lb ft (1100 Nm) |
| Torque Measured @ | 1000 rpm |
Operational
| Number Of Axels | 2 |
| Carrier Fuel Capacity | 116.3 gal (440 L) |
| Carrier Hydraulic System Fluid Capacity | 100.4 gal (380 L) |
| Tire Size | 14.00 x 20 x 20 PR |
Transmission
| Transmission Type | Allison Fully Automatic |
| Number Of Forward Gears | 6 |
| Max Speed - Forward | 46.7 mph (75 km/h) |
