Tadano TG500E
Browse All Tadano or Hydraulic Truck Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 34.95 ft in (10.65 m) |
| Max Height @ Max Raise Angle - No Jib | 131.24 ft in (40 m) |
| Max Elevating Angle | 80 degrees |
| Swing Speed | 2 rpm |
| Max Lift Capacity | 110231.13 lb (50000 kg) |
| Number Of Sections | 5 |
Dimensions
| Transport Length | 42.52 ft in (12960 mm) |
| Transport Width | 9.26 ft in (2820 mm) |
| Transport Height | 12.24 ft in (3730 mm) |
| Width W/ Outriggers Extended | 22.31 ft in (6800 mm) |
| Upper Structure Tail Swing Radius | 11.75 ft in (3580 mm) |
Carrier Engine
| Make | Tadano |
| Model | RF8 |
| Gross Power | 335.3 hp (250 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 867.4 lb ft (1176 Nm) |
| Torque Measured @ | 1400 rpm |
| Displacement | 1036.9 cu in (17 L) |
| Number Of Cylinders | 8 |
Operational
| Operating Weight | 85539.4 lb (38800 kg) |
| Carrier Fuel Capacity | 79.3 gal (300 L) |
| Upper Structure Hydraulic System Fluid Capacity | 162.5 gal (615 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 amps |
| Tire Size | 12R22.5 152/148K |
Transmission
| Transmission Type | Synchromesh and constantmesh |
| Number Of Forward Gears | 7 |
| Number Of Reverse Gears | 1 |
| Max Speed - Forward | 42.3 mph (68 km/h) |
