Komatsu PC250LC-6
Browse All Komatsu or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 31.81 ft in (9695 mm) |
| Shipping Height Of Unit | 10.16 ft in (3095 mm) |
| Max Cutting Height | 30.52 ft in (9300 mm) |
| Max Loading Height | 21.35 ft in (6505 mm) |
| Max Reach Along Ground | 29.65 ft in (9035 mm) |
| Max Vertical Wall Digging Depth | 16.18 ft in (4930 mm) |
| Max Digging Depth | 18.41 ft in (5610 mm) |
| Boom/Stick Option (Hex) 1 | Boom 19'2" (5850mm)/Stick 6'7" (2000mm) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 32.26 ft in (9830 mm) |
| Max Cutting Height | 30.65 ft in (9340 mm) |
| Shipping Height Of Unit | 12.55 ft in (3825 mm) |
| Max Loading Height | 20.84 ft in (6350 mm) |
| Max Reach Along Ground | 30.99 ft in (9445 mm) |
| Max Vertical Wall Digging Depth | 16.59 ft in (5055 mm) |
| Max Digging Depth | 20.03 ft in (6105 mm) |
| Boom/Stick Option (Hex) 2 | Boom 19'2" (5850mm)/Stick 8'2" (2500mm) |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 32.09 ft in (9780 mm) |
| Max Cutting Height | 31.7 ft in (9660 mm) |
| Max Loading Height | 22.15 ft in (6750 mm) |
| Shipping Height Of Unit | 10.6 ft in (3230 mm) |
| Max Reach Along Ground | 32.75 ft in (9980 mm) |
| Max Vertical Wall Digging Depth | 19.31 ft in (5885 mm) |
| Max Digging Depth | 21.82 ft in (6650 mm) |
| Boom/Stick Option (Hex) 3 | Boom 19'2" (5850mm)/Stick 10'0" (3050mm) |
Boom/Stick Option (Hex) 4
| Shipping Length Of Unit | 32.06 ft in (9770 mm) |
| Shipping Height Of Unit | 10.7 ft in (3260 mm) |
| Max Cutting Height | 32.09 ft in (9780 mm) |
| Max Loading Height | 23.38 ft in (7125 mm) |
| Max Reach Along Ground | 34.08 ft in (10385 mm) |
| Max Digging Depth | 23.32 ft in (7105 mm) |
| Max Vertical Wall Dig Depth | 20.23 ft in (6165 mm) |
| Boom/Stick Option (Hex) 4 | Boom 19'2" (5850mm)/Stick 11'6" (3500mm) |
Dimensions
| Ground Clearance | 1.65 ft in (500 mm) |
| Height To Top Of Cab | 9.91 ft in (3020 mm) |
| Width To Outside Of Tracks | 10.8 ft in (3290 mm) |
| Length Of Track On Ground | 12.95 ft in (3945 mm) |
| Tail Swing Radius | 9.39 ft in (2860 mm) |
| Removal Counterweight Clearance | 3.96 ft in (1205 mm) |
Undercarriage
| Track Gauge | 8.5 ft in (2590 mm) |
| Shoe Size | 27.56 in (700 mm) |
| Ground Pressure | 6.5 psi (44.82 kPa) |
| Max Travel Speed | 3.17 mph (5.1 km/h) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2238 |
| Engine Model | SA6D102 |
| Net Power | 171.7 hp (128 kw) |
| Power Measured @ | 2300 rpm |
| Displacement | 358.9 cu in (5.9 L) |
Operational
| Operating Weight | 60627.2 lb (27500 kg) |
| Fuel Capacity | 81.9 gal (310 L) |
| Hydraulic System Fluid Capacity | 43.9 gal (166 L) |
| Hydraulic System Relief Valve Pressure | 5050 psi (34818.5 kPa) |
| Hydraulic Pump Flow Capacity | 113.6 gal/min (430 L/min) |
Swing Mechanism
| Swing Speed | 11.5 rpm |
Buckets
| Reference Bucket Capacity | 1.4 yd3 (1.1 m3) |
| Minimum Bucket Capacity | 1 yd3 (0.8 m3) |
| Maximum Bucket Capacity | 2.1 yd3 (1.6 m3) |
