Hitachi EX280LCH-5
Browse All Hitachi or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 33.76 ft in (10290 mm) |
| Shipping Height Of Unit | 10.41 ft in (3170 mm) |
| Max Cutting Height | 32.75 ft in (9980 mm) |
| Max Loading Height | 23.2 ft in (7070 mm) |
| Max Reach Along Ground | 35.14 ft in (10710 mm) |
| Max Vertical Wall Digging Depth | 20.05 ft in (6110 mm) |
| Max Digging Depth | 23.73 ft in (7230 mm) |
Dimensions
| Ground Clearance | 1.65 ft in (500 mm) |
| Height To Top Of Cab | 9.98 ft in (3040 mm) |
| Width To Outside Of Tracks | 10.47 ft in (3190 mm) |
| Length Of Track On Ground | 13.29 ft in (4050 mm) |
| Tail Swing Radius | 9.65 ft in (2940 mm) |
| Removal Counterweight Clearance | 3.81 ft in (1160 mm) |
Undercarriage
| Max Travel Speed | 2.74 mph (4.41 km/h) |
| Ground Pressure | 7.69 psi (53 kPa) |
Engine
| Engine Make | 2511 |
| Engine Model | H07C-TD |
| Net Power | 167.7 hp (125 kw) |
| Power Measured @ | 2050 rpm |
Operational
| Operating Weight | 61949.9 lb (28100 kg) |
| Fuel Capacity | 100.4 gal (380 L) |
Swing Mechanism
| Swing Speed | 10.6 rpm |
Buckets
| Reference Bucket Capacity | 1.5 yd3 (1.1 m3) |
