Tata Hitachi ZAXIS450LCH
Browse All Tata Hitachi or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Cutting Height | 34.95 ft in (10650 mm) |
| Max Loading Height | 23.99 ft in (7310 mm) |
| Max Reach Along Ground | 33.5 ft in (10210 mm) |
| Max Vertical Wall Digging Depth | 13.98 ft in (4260 mm) |
| Max Digging Depth | 19.03 ft in (5800 mm) |
| Boom/Stick Option (Hex) 1 | Boom 6300mm/Stick 2500mm |
Boom/Stick Option (Hex) 2
| Max Cutting Height | 35.08 ft in (10690 mm) |
| Max Loading Height | 24.09 ft in (7340 mm) |
| Max Reach Along Ground | 34.78 ft in (10600 mm) |
| Max Vertical Wall Digging Depth | 16.25 ft in (4950 mm) |
| Max Digging Depth | 20.44 ft in (6230 mm) |
| Boom/Stick Option (Hex) 2 | Boom 6300mm/Stick 2900mm |
Boom/Stick Option (Hex) 3
| Max Cutting Height | 33.7 ft in (10270 mm) |
| Max Loading Height | 23.1 ft in (7040 mm) |
| Max Reach Along Ground | 36.72 ft in (11190 mm) |
| Max Vertical Wall Digging Depth | 15.69 ft in (4780 mm) |
| Max Digging Depth | 23.96 ft in (7300 mm) |
| Boom/Stick Option (Hex) 3 | Boom 7000mm/Stick 2900mm |
Boom/Stick Option (Hex) 4
| Max Cutting Height | 36.36 ft in (11080 mm) |
| Max Loading Height | 25.14 ft in (7660 mm) |
| Max Reach Along Ground | 38.75 ft in (11810 mm) |
| Max Digging Depth | 25.46 ft in (7760 mm) |
| Boom/Stick Option (Hex) 4 | Boom 7000mm/Stick 3400mm |
| Max Vertical Wall Dig Depth | 21.66 ft in (6600 mm) |
Dimensions
| Ground Clearance | 2.43 ft in (738 mm) |
| Height To Top Of Cab | 11.06 ft in (3370 mm) |
| Width To Outside Of Tracks | 11.46 ft in (3490 mm) |
| Tail Swing Radius | 11.49 ft in (3500 mm) |
| Removal Counterweight Clearance | 4.43 ft in (1350 mm) |
Undercarriage
| Track Gauge | 9.49 ft in (2890 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
| Number Of Shoes Per Side | 53 |
| Number Of Carrier Rollers Per Side | 3 |
| Number Of Track Rollers Per Side | 9 |
| Ground Pressure | 11.61 psi (80 kPa) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2353 |
| Engine Model | AA-6WG 1TQA |
| Net Power | 315.2 hp (235 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 940.4 lb ft (1275 Nm) |
| Displacement | 957 cu in (15.7 L) |
| Aspiration | turbocharged |
| Torque Measured @ | 1500 rpm |
Operational
| Operating Weight | 103837.8 lb (47100 kg) |
| Fuel Capacity | 171.8 gal (650 L) |
| Cooling System Fluid Capacity | 16.2 gal (61 L) |
| Hydraulic System Fluid Capacity | 21.2 gal (80 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 14.6 gal (55 L) |
| Swing Drive Fluid Capacity | 1.8 gal (6.5 L) |
| Hydraulic System Relief Valve Pressure | 4974.8 psi (34300 kPa) |
| Hydraulic Pump Flow Capacity | 190.3 gal/min (720 L/min) |
Swing Mechanism
| Swing Speed | 9 rpm |
Buckets
| Reference Bucket Capacity | 2.5 yd3 (1.9 m3) |
| Minimum Bucket Capacity | 2.5 yd3 (1.9 m3) |
| Maximum Bucket Capacity | 4 yd3 (3 m3) |
