Sunward SWE225LC
Browse All Sunward or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 31.34 ft in (9550 mm) |
| Shipping Height Of Unit | 9.73 ft in (2965 mm) |
| Max Cutting Height | 31.62 ft in (9635 mm) |
| Max Loading Height | 22.28 ft in (6790 mm) |
| Max Reach Along Ground | 32.44 ft in (9885 mm) |
| Max Vertical Wall Digging Depth | 19.48 ft in (5935 mm) |
| Max Digging Depth | 22.09 ft in (6730 mm) |
| Boom/Stick Option (Hex) 1 | Boom 5700m/Stick 2920mm |
Dimensions
| Ground Clearance | 1.55 ft in (470 mm) |
| Height To Top Of Cab | 9.73 ft in (2965 mm) |
| Width To Outside Of Tracks | 9.81 ft in (2990 mm) |
| Tail Swing Radius | 9.03 ft in (2750 mm) |
| Removal Counterweight Clearance | 3.55 ft in (1080 mm) |
Undercarriage
| Track Gauge | 7.85 ft in (2390 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Max Travel Speed | 3.08 mph (4.95 km/h) |
Engine
| Engine Make | 2353 |
| Engine Model | 6BG1TC |
| Net Power | 167.7 hp (125 kw) |
| Max Torque | 514.1 lb ft (697 Nm) |
| Aspiration | turbocharged |
| Displacement | 396.3 cu in (6.5 L) |
Operational
| Operating Weight | 49824.5 lb (22600 kg) |
| Fuel Capacity | 97.8 gal (370 L) |
| Hydraulic System Fluid Capacity | 66.1 gal (250 L) |
| Hydraulic System Relief Valve Pressure | 4699.3 psi (32400 kPa) |
| Hydraulic Pump Flow Capacity | 116.3 gal/min (440 L/min) |
Swing Mechanism
| Swing Speed | 11.6 rpm |
