New Holland E305EL
Browse All New Holland or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 34.36 ft in (10470 mm) |
| Shipping Height Of Unit | 11.46 ft in (3490 mm) |
| Max Cutting Height | 31.98 ft in (9747 mm) |
| Max Loading Height | 22.9 ft in (6978 mm) |
| Max Reach Along Ground | 31.59 ft in (9628 mm) |
| Max Vertical Wall Digging Depth | 19.8 ft in (6034 mm) |
| Max Digging Depth | 20.52 ft in (6254 mm) |
| Boom/Stick Option (Hex) 1 | monoblock boom / stick 2100mm |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 34.03 ft in (10370 mm) |
| Max Cutting Height | 32.62 ft in (9942 mm) |
| Shipping Height Of Unit | 11.19 ft in (3410 mm) |
| Max Loading Height | 23.39 ft in (7128 mm) |
| Max Reach Along Ground | 32.56 ft in (9924 mm) |
| Max Vertical Wall Digging Depth | 20.86 ft in (6357 mm) |
| Max Digging Depth | 21.51 ft in (6554 mm) |
| Boom/Stick Option (Hex) 2 | monobloc boom / stick 2400mm |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 33.7 ft in (10270 mm) |
| Max Cutting Height | 33.57 ft in (10232 mm) |
| Max Loading Height | 24.29 ft in (7402 mm) |
| Shipping Height Of Unit | 10.37 ft in (3160 mm) |
| Max Reach Along Ground | 34.67 ft in (10565 mm) |
| Max Vertical Wall Digging Depth | 23.26 ft in (7088 mm) |
| Max Digging Depth | 23.8 ft in (7254 mm) |
| Boom/Stick Option (Hex) 3 | monobloc boom / stick 3100mm |
Boom/Stick Option (Hex) 4
| Shipping Length Of Unit | 33.73 ft in (10280 mm) |
| Shipping Height Of Unit | 10.5 ft in (3200 mm) |
| Max Cutting Height | 34.89 ft in (10632 mm) |
| Max Loading Height | 25.5 ft in (7770 mm) |
| Max Reach Along Ground | 36.8 ft in (11215 mm) |
| Max Digging Depth | 25.94 ft in (7904 mm) |
| Max Vertical Wall Dig Depth | 25.47 ft in (7763 mm) |
| Boom/Stick Option (Hex) 4 | monobloc boom / stick 3750mm |
Dimensions
| Ground Clearance | 1.77 ft in (539 mm) |
| Height To Top Of Cab | 10.41 ft in (3170 mm) |
| Width To Outside Of Tracks | 10.47 ft in (3190 mm) |
| Length Of Track On Ground | 13.16 ft in (4010 mm) |
| Tail Swing Radius | 9.68 ft in (2950 mm) |
| Removal Counterweight Clearance | 4.09 ft in (1245 mm) |
Undercarriage
| Track Gauge | 8.5 ft in (2590 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Ground Pressure | 8.71 psi (60 kPa) |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
| Number Of Carrier Rollers Per Side | 2 |
| Number Of Track Rollers Per Side | 9 |
Engine
| Number Of Cylinders | 6 |
| Engine Model | CNH 667TA/EEC |
| Net Power | 201 hp (149.9 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 627 lb ft (850 Nm) |
| Displacement | 408.9 cu in (6.7 L) |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 69577.9 lb (31560 kg) |
| Fuel Capacity | 118.1 gal (447 L) |
| Cooling System Fluid Capacity | 6.1 gal (23 L) |
| Hydraulic System Fluid Capacity | 74 gal (280 L) |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 4.5 gal (17 L) |
| Alternator Supplied Amperage | 70 amps |
| Hydraulic System Relief Valve Pressure | 4974.8 psi (34300 kPa) |
| Hydraulic Pump Flow Capacity | 127.4 gal/min (482 L/min) |
Swing Mechanism
| Swing Speed | 11 rpm |
Buckets
| Reference Bucket Capacity | 1.5 yd3 (1.1 m3) |
| Minimum Bucket Capacity | 0.8 yd3 (0.6 m3) |
| Maximum Bucket Capacity | 2.2 yd3 (1.7 m3) |
